GOLDRING LOUDSPEAKER E1

Description

Goldring's philosophy is the promotion of precise reproduction of the original production
recordings, preservation of creative nuances, musicality and rhythm which
is intended for you to hear. With the versatile E series, that
is easy to achieve: each is designed to be simple
installed on the vast majority of record players in the middle price range. E1 speaker,
the first in the series, uses a carrier reinforced with carbon fibers and connected,
spherical (0.6 mil) stylus with round shoulder. Carbon is efficient
an alternative to more expensive materials such as aluminum or boron,
providing comparable results in most entry-level Hi-Fi applications.

SPECIFICATIONS (eng):

Colour
Order
Cantilever
Carbon
Stylus profile
Spherical
Stylus radius
0.6 million
Frequency range
20 Hz - 20 kHz
Channel balance
1.5 dB at 1 kHz
Channel separation
>20 dB at 1 kHz
Sensitivity
3.5 mV (1 kHz @ 5 cm/sec)
Static compliance
20 mm/N
Vertical tracking angle
20°
Load resistance
47 kΩ
Load capacitance
100 - 200 pF
Internal inductance
400 mH
Internal resistance
410 Ω
Cartridge mass
6.9 g
Fixing centers
12.7 mm (0.5 in)
Playing weight
1.5 g - 2.5 g (2.0 g recommended)
