iFi Audio xDSD Gryphon

Description

iFi Audio xDSD Gryphon Portable DAC and Headphone Amplifier

iFi Audio's new xDSD Gryphon is an improved version of the original xDSD, with an upgraded headphone stage and separate bluetooth and DAC stages, meaning there are dedicated components to handle each task to ensure optimal performance. The Gryphon also has 3.5mm or 4.4mm outputs, allowing compatibility with a wide range of headphones.

What iFi Audio says

A hi-fi system in your pocket

Premium HD DAC + powerful balanced front end.

Portable DACs/amplifiers are often compromised because they focus on either the great digital OR the great analog part. But not both. The xDSD Gryphon is different. Like its mythical namesake, it is two beasts in one.

From the Ultra-Res digital stage that uses a Burr-Brown MultiBit at its core to the PureWave analog power section that pumps out 1000mW and everything in between, it takes some serious headphones to tame the Gryphon.

Well connected

• Separate Bluetooth + DAC + amplifier stages: each optimized for maximum performance
• Digital sources via USB, S/PDIF or Bluetooth
• Analog sources via 4.4 mm or 3.5 mm input

Brilliant Bluetooth. Hi-Res wireless.

Using the latest QCC 5100 series Bluetooth v5.1 as the starting point for wireless connectivity, the xDSD Gryphon is at the cutting edge of the latest formats:

• aptX Adaptive and aptX HD
• LDAC and HWA/LHDC
• Regular aptX and aptX low latency
• AAC
• SBC (Standard Bluetooth)

Not only that, but the above is on the iFi digital platform where each section is separate. So QC5100 for reception > Global Master Clock for jitter > Burr-Brown for DAC conversion. More effort, but that's why our wireless network prefers wired.

Specifications

Come in

• Wireless:
  • Bluetooth 5.1 (aptX, aptX HD, aptX Adaptive, aptX LL, LDAC, HWA, AAC and SBC codec)
• Wired (digital):

  • USB-C
  • S/PDIF coaxial
• Wired (analog):

  • Balanced 4.4 mm
  • One-sided 3.5 mm

Formats

• DSD: DSD512/256/128/64, Octa/Quad/Double/Single-Speed
• PCM: 768/705.6/384/352.8/192/176.4/ 96/88.2/48/44.1kHz
• DXD: 768/705.6/384/352.8 kHz, Dual/Single Speed ​​DXD
• MQA (decoder): 384/352.8 kHz
• Bluetooth: up to 96kHz

• DAC: Burr-Brown
• Battery: USB-C charging. Complies with BC1.2 up to 1900mA charging current
• Dimensions:

  • 123x75x19 mm
  • 4.8"x3.0"x0.7"

Line section

• Exits:
  • Balanced: 6.7 V max. (variable)
  • S-Bal (SE): 3.5 V max. (variable)
• Output impedance:
  • Balanced: ≤200Ω
  • S-Bal (SE): ≤100Ω
  • Balanced: <110dB(A) @ 0dBFS
  • S-Bal (SE): <110dB(A) @ 0dBFS
  • Balanced: <0.007% @ 0dBFS
  • S-Bal (SE): <0.015% @ 0dBFS

Headphone compartment

• Exits:
  • Balanced: 4.4mm Pentaconn
  • S-Bal (SE): 3.5 mm SE
• Output power:
• Balanced:

  • >1000mW at 32Ω
  • >74mW at 600Ω
  • >6.7 V max. @ 600Ω
• S-Bal (SE):

  • >320mW at 32Ω
  • >40mW at 300Ω
  • >3.5 V max. @ 600Ω
• Output impedance:
  • Balanced: <1Ω
  • S-Bal (SE): <1Ω

• SNR:

  • Balanced: <116dB(A) @ 0dBFS
  • S-Bal (SE): <115dB(A) @ 0dBFS
• THD+N: <0.005% (1V @ 16Ω)
